Ping 192.168.1.1 – t Explained

Standard

Have you ever been in a situation to have some networking or internet connectivity problems? Have you checked your router LED lights and connections and everything seemed normal? Well, when we have to deal with network problems we can say that the PING command is a very useful tool. Sometimes the reasons for networking problems can’t be easily discovered. Here the ping command can point us to the right direction and help us resolve the problem much faster. For example, with the ping command we can do the following:

  • Test the connectivity between the router and the PC (ping the router default IP address)
  • Verify connectivity to the Internet (ping a website)
  • Verify the network activity

When we perform this action, our PC sends packets to the router, and the router sends replies. By doing this we can make sure that the connection between them is fine. However, in this article we are going to tell you more about the so called “continuous ping”, and just to make thing clear we will use 192.168.1.1 as an example, because many router brands like Linksys, Netgear, TP-Link and so on, use it as their default router IP.

Ping 192.168.1.1 or Ping 192.168.1.1 – t

ping router ip address

Ping 192.168.1.1 can be referred to as a ping. During this process 4 packets of data are being sent. In most cases it isn’t enough to determine whether there is a problem or not, so we would probably have to repeat the ping command several times. That is why the following is ideal for us.

Continuous - ping 192.168.1.1 -t

Ping 192.168.1.1 -t is called a continuous ping. During this process the -t switch will initiate the so called “continuous ping” which will go on until the user interrupts it. Basically packets of data are being sent continuously. In order to stop the pinging the user has to press Ctrl + C or Ctrl + Break (Pause) on the keyboard to receive a summary of all the pings, both sent and received. The only difference is that pressing Ctrl + C will stop the ping completely, while Ctrl + Break will give us the summary until that moment and then continue.

Continuous Ping Uses

When we perform a continuous ping, in this case by using the command “ping 192.168.1.1 -t” we can see the number or percentage of lost packets, and also notice the consistency of the response time. Additionally, if we want to check whether we have a stable connection this is the right option. Getting a Reply from continuously indicates a stable connection. On the other hand, getting too much Request timed out will indicate an unstable connection.

Also if you suspect that you have wiring and cabling problems, the command “ping 192.168.1.1 -t” will let you notice the moments when the problems occur.

If we do a continuous ping to our device such as printer or server, we can check if they are active.

How to perform a continuous ping

We have already mentioned that in this article we are going to use a router with a default IP 192.168.1.1. In case you have checked your router IP address and it is 192.168.2.1 or 192.168.0.1 just use that IP in the command.

We will describe the process step by step in Windows 7. The steps are the same except of the first step where we have to start up the Command prompt.

1. Click the start button.

start button in Windows 7

2. In the Search box type CMD and the command prompt will open.

type CMD

3. In the Command prompt window type

ping 192.168.1.1 -t

(make sure to add a blank space before -t)

Additionally, make sure not to type 192.168.l.l. This is a common typing error so we had to mention it.

4. Press the Enter button on the keyboard and the continuous ping will begin.

5. When you are ready to stop, press Ctrl + C or Ctrl + Break (Pause) on your keyboard.

Watch this video to learn how to find the router IP and how to ping your router.

6. Analyze the ping results.

ping results

Ping responses overview

Reply from – This response, along with 0% loss, indicates a stable connection.

Request Timed Out – This response is generally received when the pinged destination/host is not working.

Destination Network or Host unreachable – If there is a problem in the communication between the router and the PC you can get this response. Basically, this means the router didn’t give the PC an IP address. In this case, check the following:

  • Check the IP address of your router by using the IPCONFIG command in the Command prompt. Your computer IP is the IPv4 IP address.  The router address is the Default gateway.
  • Check the PC-router connections. See if the LED lights are working and ping the router.
  • Verify the connection to the Internet by pinging a website (for example, ping www.yahoo.com)

Unknown Host – This response indicates that the IP you want to ping can’t be recognized by your PC or that there are some DNS issues (your PC isn’t getting a valid IP). In the first case, it is generally recommended to check that you have typed the IP correctly (we have already mentioned that some users type 192.168.l.l. Remember that the IP is made of numbers so instead of l.l we have to type 1.1). In the second case you will have to release and renew the computer IP address.  To release an IP address  open the Command prompt and type “ipconfig /release” an press the Enter button on your keyboard. After that in the Command prompt type “ipconfig /renew” to obtain a new IP.

Hardware Error – When you get this response check if the router is plugged in and if all the cables are firmly connected.

Analyzing the ping results

Analyzing the ping summary can tell us what the problem can be. However, we have to take care of several different types of data:

Ping statistics for 192.168.1.1:

Here we can see the number of packets – sent, received and lost. Ideally the numbers of sent and received packets should be equal and the number of lost packets equal to 0%.

Please not that the duration of the pinging can result in dropping one or more packets, but if the number is still at 0%, you have nothing to worry about. However, if you have received a 100% loss, check your router’s IP address. Additionally, you can, check if everything is properly connected. Check if your firewall is blocking the pings. Restart your router and try again. Ping from another PC, or connect and ping another router. This will help in narrowing the problem identification.

Approximate round trip times in milli-seconds

Here we can apply the rule “the lower, the better“. In case these numbers are higher it indicates a network problem.

Final Words

As you can see from the details given above, the continuous ping command, in this case “ping 192.168.1.1 -t” is valuable in the terms of detecting the possible networking problem cause. Since it doesn’t take anything except a little of our time when we perform it, it is certainly worth trying it whenever we have some networking problems.

Testing the computer-router connection

Standard

The ping command is a handy little utility in Windows, Mac and Linux based operating systems. This diagnostic utility sends a request (a signal, packets of data) to a specific target (router’s default IP address or website URL) and measures the number of replies versus the number of sent signals, and the time between the sending of the signal and the reply. Although quite simple, the ping utility is one of the tools mostly used in network troubleshooting.

One of the basic uses of this tool is to test the communication between the computer and the router and see if it functions properly.

Pinging the router IP address in Windows 7

1. Open up the Start menu in Windows 7 and type CMD in the Search Programs and Files field.

cmd

2. When the Command Prompt opens (read here how to open it in Windows 8), you should type ping and then the routers default IP address. For example, if you have a Linksys router the command should look like this:

 ping 192.168.1.1

 3. Press Enter on the keyboard.

4. After 4 packets of data being sent, the result window will appear.

ping-results

If you want to test the communication for a longer time use the Continuous ping command: ping 192.168.1.1 -t. This command sends unlimited number of signals until the user stops it.

If the communication between the computer and the router is functioning properly you will see the following:

Reply from 192.168.1.1: bytes=32 time=xx ms TTL=xx

The time and TTL values may vary because of different reasons that is why we have we added xx at their end.

However, if there is a problem in the communication you will receive a Request timed out message.

Why did I get Request timed out message?

The 2 main causes of the Request timed out message are:

• Wrong network configuration

- In this case it is good to check if the Network drivers are properly installed along with the TCP/IP

- Check if you have pinged the right router IP address, generally they start with 192.168.

• Bad physical connections

To check this, take a look at the LAN port. It should be ON. However, in case it is OFF do the following:

- Check if the Ethernet cable is firmly connected to the router and the computer.

- Check if the computer is turned ON

- Check if the lights on the computer’s Ethernet card are on.

Well, now you know how to test the connection between your PC and the router and whenever you experience some problems it is worth trying the ping command.
